Specifications for weight distribution and bridge laws

Truck salespeople, fleet managers and end users face challenges in determining the right work truck for a specific application. When replacing a commercial vehicle with something similar, the first inclination is often to copy the existing work truck specifications into the replacement vehicle. However, with the variety of advancements in vehicle technologies and chassis changes year-to-year, a more systematic approach is warranted. Assessing user needs and expectations is key to the successful selection of any work truck. User needs can include identification of: Desired truck body and equipment, such as liftgates, cranes or other work equipment. Expected payload needs, which help shape the work truck’s size, weight class and gross vehicle weight rating (GVWR) needed to properly perform a function. For example, GVWR may be specified to avoid a commercial driver’s license (CDL) for electrical technicians who use the vehicle to perform duties but are not truck drivers, or to circumvent service hour restrictions for repair technicians. Note, chassis GVWR limitations to avoid CDL requirements will directly affect equipment and payload the specific chassis can haul. One of the first steps in creating a robust truck specification is performing a payload analysis. This involves reviewing the proposed chassis, body, equipment, accessory and occupant weights, and comparing them to the proposed vehicle’s GVWR. The remaining weight is the available cargo capacity. If the resulting cargo is sufficient for your work truck needs, the next step is to perform a full weight distribution analysis, which will allow you to determine if the desired chassis is suitable for the application. Another parameter to consider when creating a vehicle specification is gross axle weight rating (GAWR). This is the maximum weight an individual axle can carry when measured at the tire-to-ground interface. GAWR is a critical element in weight distribution calculations because it will either confirm the truck can be built as specified or signal that adjustments must be made to equipment placement or cargo in order for the vehicle, when loaded, to remain within its respective weight ratings. This is a critical point for the vehicle upfitter in their motor vehicle safety compliance determinations, and any specifics related to vehicle loading in practice should be factored into the analyses. It can be easy to overlook occupant weight, but the weight and location associated with all designated seating positions must be included in the analyses, which may result in necessary changes for the amount and/or placement of cargo and equipment, accordingly. While any given vehicle could be loaded in excess of its ratings in practice, a thorough weight analyses goes a long way toward ensuring the proper chassis is being considered for the application. Federal bridge formula Once the application is determined suitable for a given chassis’ GVWR and GAWRs, any applicable bridge weight limitations can be assessed. This is done by comparing the calculated axle loads against state and federal maximum roadway weight laws. In the U.S., the interstate highway system and federally designated roads in each state use the federal bridge formula to determine maximum allowable truck weight on their respective roads. Many states have different weight restrictions for roads under their control (non-interstate and federally designated roads); however, there are some exceptions. Additionally, some states have seasonal restrictions for roadways, commonly known as frost laws, where weights are reduced for certain periods of the year. Bridge weight limits apply to individual axle weights, axle grouping weights and total vehicle weights. For example, under the federal bridge formula, the amount of weight a single drive axle can carry is limited to a maximum of 20,000 pounds (34,000 pounds for a tandem axle system). The full weight the truck is allowed to carry is based on total number of axles and distance from center of the forward-most axle to the rearward-most axle, known as the outer bridge. However, the total weight can be further limited by inner axle groupings. To illustrate, consider a three-axle truck consisting of a steering axle and tandem rear axle, with a 214-inch wheelbase, 58,000-pound GVWR, front axle rated at 18,000 pounds GAWR and rear tandem axle rated at 40,000 pounds GAWR. Take into account the wheelbase dimension is measured from the front axle to the center of the tandem. The additional distance from the center of the tandem axle to the center of the rearmost axle needs to be added to the wheelbase to determine distance from steering axle to rearmost axle. In this example, that distance is 240 inches or 20 feet. This dimension will be important in establishing the truck’s total carrying capacity under the federal bridge formula. According to the federal bridge formula table, for a truck with three axles and a distance of 20 feet between the extremes of a group of two or more consecutive axles, maximum total allowable weight is 51,000 pounds. A comparison of vehicle axle ratings and weight law limitations shows the rear tandem axle has a greater capacity at 40,000 pounds than the weight law of 34,000 pounds — thus, requiring payload capacity stay within the 34,000-pound tandem federal weight law limitation (your state may have a higher road limit). The weight distribution performed earlier can help you verify the new payload or if the front axle rating will permit equipment repositioning to allow for additional payload. This weight law limitation is common in heavy-duty truck chassis normally greater than 33,000 pounds GVWR. For most light- and medium-duty vehicles, normally ranging from 6,000–32,000 pounds GVWR, federal and state weight law limitations will not typically affect maximum vehicle weight, and your truck’s GVWR and GAWRs will be the primary factors in defining maximum payload. When determining chassis specifications for a work truck, it’s important to fully understand the end user’s body, equipment and payload needs to properly size the chassis for safety, durability and customer satisfaction. Combined with an understanding of weight distribution and weight law analysis, you can successfully deliver a safe and proper truck. Access additional whitepapers at ntea.com/whitepapers.

Specifications for weight distribution and bridge laws
